Diesel Driven Emergency Response Pumping Station Kit

Complete kit containing all necessary suction and delivery fittings and pipework to assemble an emergency response pumping station. The set can be used to pump water from a surface source or from a tank. General purpose 2″ x 2″ air cooled diesel engine with recoil start, all cast iron construction, mounted in a tubular steel roll frame and supplied with sufficient spares and accessories for one full year of operation (per manufacturers guidelines). Based on the performance curve for this pump, the following capacities can be achieved: 43m³ / hour at 10m head, 28m³ / hour at 20m head, 8m³ / hour at 30m head.

For technical help and advice we recommend visiting our specialist Pump Division.

This kit is supplied in accordance with the following agency specifications:

UNICEF_SM





Description

UNICEF order code: S5006061

Product Specifications

Kit supplied with:

  • 30m 3″ Medium duty semi rigid hose with footvalve fitted
  • 3m 3″ Transparent medium duty PVC hose with gate valve
  • Sufficient fittings to allow connection to a 3″ pumping main
  • Pump spares and engine consumables including filters, seals, gaskets
  • 5 litres engine oil
  • Installation, operation and maintenance manuals

Additional packing Information: Complete set is packed in an ISPM15 heat treated plywood case suitable for export.

18 Units will fit into a 20ft container

38 Units will fit into a 40ft container

More detailed information will be provided upon receipt of your quotation request.

Weight 252 kg
Dimensions 122 × 110 × 110 cm
